Walkaround #1042

F-5 Sonic Boom Test Prototype

Reference photos by Justin Davenport

This is the DARPA F-5 Sonic Boom prototype from the front





These photos were taken at the Valiant Air Command museum in Titusville, Florida in 2007.

Justin Davenport

Click on images below to see larger images

Note the DARPA logo near the front

Nice closeup of the left air intake and stenciling
NASA isn't just a space agency.  They also do aeronautics research
This jet was used to research ways to quiet the sonic boom of jets flying past Mach 1



Click on images below to see larger images

This aircraft was modified  from a regular F-5E airframe

Nice shot of the bird with Old Glory
This is one of a number of aircraft viewable at the Valiant Air Command museum



Photos and text by Justin Davenport
