Heinkel He162

These photos were taken by Steve Hubbard

(click on the image below to load the full size photo)

(use your back button to return to this page after viewing full size photo)

Photos directly below were taken at R.A.F. Museum, Hendon, London on 15th December 2003.

Tail Section

Engine Cockpit Undercarriage

Heinkel He162 - tail section seen from the starboard rear.

Heinkel He162 - Engine pod.

Heinkel He162 - Cockpit section. The He162 was the first production a/c to feature an ejection seat. The seat for this particular a/c went missing a few years ago and no replacement is available.

Heinkel He162 - Undercarriage.



Starboard Nose

Port Nose

Heinkel He162 - Nose from the starboard side. Heinkel He162 - Nose from the port side.

Photos and text 2004 by Steve Hubbard
